Features:

• Rockville D14 7000w Peak/2000w RMS Class D 2 Channel Power Amplifier Pro/DJ Amp

• LCD displays volume in dB per channel and operating temperature

• 1.5U rack space

• Built in limiter protects your speakers from distortion and clipping

• Bridged mode allows you to combine both channels power into one channel for use with a subwoofer

• Stereo mode is perfect for (2) speakers or (4) speakers in a left and right configuration

• Parallel mode gives you dual mono output signal which is perfect for monitor use when you want all sounds coming out of each speaker instead of a left/right configuration

• Built in crossover switch (bypass, 80 Hz, 160 Hz) allows amp to be used with full range PA speakers, or Subwoofer(s)

• Channel A & B Clipping Led Indicators

• Channel A & B Separate Level Controls

• Power, signal, clipping, and protection LED indicators on front of amp

• Heavy duty rack mount ears with handles

• Built-in variable high velocity quiet cooling fans

• Maximum headroom for 4-ohm and 8-ohm Speakers

• Level controls for precise setting and matching of sensitivity

• Computer controlled IC protection circuitry against speaker short circuit, thermal over load, DC over load

• User serviceable fuse (20A, 250V)

• Frequency Response (bandwidth @ 2Vrms out, @ -3.0dB) 10 Hz – 30 Khz

• THD + Noise @ 1Khz full power: <0.18%

• Input Impedance: 10K Ohm Balanced

• Input signal voltage: 640mV – 2.7V

• Input sensitivity: 0.7v

• Damping factor: ( 100Hz, 10w, 4 ohms): 44.1

• Damping factor: (1Khz @ 8 ohm): >400:1

• Effective damping factor (100Hz, 10w, 4 Ohms) 1.08

• Output impedance at speaker terminals: 0.0901 Ohms

• Frequency Response vs THD+N (worst case, across normal bandwidth 1W) 0.09%

• Signal to Noise Ratio: > 100dB

• IMD 60Hz & 1kHz, 4:1: <0.04%

• SLEW RATE (input filter limited) : 28v/uS

• Power Requirements: 100V-240V / 50-60Hz

• Weight: 9.9 lbs

• Dimensions: 19.09 x 9 x 2.56 inches

Power Ratings:

RMS Power Output:

• Stereo 8 Ohm: 2 x 700W

• Stereo 4 Ohm: 2 x 1000W

• Bridged 8 Ohm: 1 x 2000W


Peak Power Output:

• Stereo 4 Ohm: 2 x 3500W Max

• Bridged 8 Ohm: 1 x 7000W Max


​​Terminals:

Input Terminals:

• Combo jack (XLR and ¼”) A & B inputs


Output Terminals:

• Banana binding post speaker output

• Speakon output

• XLR output to connect another amplifier or powered sub
